Technical Data

Weight

• Without brakes: 540 kg (1190 lbs)
• With brakes: 605 kg (1330 lbs)

Compressor

• Operating pressures:
• 6.5 bar → 2500 l/min (88 cfm)
• 10 bar → 1900 l/min (67 cfm)
• 12 bar → 1400 l/min (50 cfm)
• Minimum working pressure: 5.5 bar
• Drive system: Belt drive
• Cooling system: Air/Oil
• Oil cooling capacity: 6 liters
• Air outlet temperature: Ambient + 40°C
• Outlet valves: 2 × 3/4"
• Noise level: < 98 LWA
• Battery: 12V – 270A – 55Ah
• Fuel tank: 30 liters
• Fuel consumption: 3.8 liters/hour (8-hour operation)

Diesel Engine

• Make: KUBOTA
• Model: D1105-E4B
• Type: 4-stroke, inline
• Emissions: Stage V A / Tier 4
• Displacement: 1123 cc
• Cylinders: 3
• Aspiration: Natural
• Max power: 18.5 kW (25 HP) @ 3600 RPM
• Engine speed range: 1900–3000 RPM
• Cooling system: Water (capacity 4 liters)
• Lubrication system: Oil (capacity 5.1 liters)

Environmental Conditions (Standard Version)

• Max ambient temperature: 50°C
• Max altitude: 1800 m
• Min working temperature: -10°C
